CYO Single-lever bath mixer with stand pipe for free-standing assembly with hand shower set - Brushed Dark Platinum
| Product Number | 25 863 811-99 |
| EAN Number | 4029011846915 |
Brushed Dark Platinum
Product Description
Our new CYO fittings series combines Dornbracht design history with the current spirit of the age – aspiring, as always, to create lasting values. You think you know the design language, yet the effect is unseen and forward looking. A commanding statement in both progressive and classic bathrooms.
| Product Number | 25 863 811-99 |
| EAN Number | 4029011846915 |
| Application area | Bath |
| Construction type | Free-standing assembly |
| Flow rate Max. | 26.5 l/min |
| Brand | Dornbracht |
Product Detail
- 247mm projection
- Rectangular, air-enriched flow
- Max. spout flow rate 26.5 l/min
- Hand shower: COMPACT RAIN, max. flow rate 6.8 l/min (at 3 bar)
- Bar-type hand shower with anti-scale system
- Wall bracket
- Automatic bath/shower diverter
- Total height 980 - 1050 mm
- Stand pipe height 598 - 668 mm
- Height up to aerator 903 – 973 mm
- Push-on rosette 131 x 131 mm
- Metal shower hose 1250mm with integrated anti-twist protection
- WRAS
Customisation Options
Dornbracht provides fittings and accessories that are perfectly tailored to individual requirements. The design can be personalised in many ways, from technical adjustments, to exclusive surface finish variants. Adaptations to dimensions such as the length and projection of the fittings, and modifications to functions such as the flow rate or the product marking, are all part of the service. Both the dimensions and functions of these products can be readily adapted.
Downloads
Here you have the opportunity to download all relevant documents. Whether brochures, instructions or important information - everything is available for download. Further technical files can be found in the technical information section further down on the product page.
